AOYI Acrylic Court Coating Technical Data Sheet (TDS)
Document Version: V1.0
Date: 2026-09-01
Product Model: Water-based Acrylic Court System
Manufacturer: Guangzhou Lianyi Chemical Co., Ltd.
Applicable Venues: Tennis courts, basketball courts, pickleball courts, volleyball courts and other outdoor sports venues
AC-SP-500 is a one-component water-based elastic acrylic sports court coating. It adopts elastic acrylic emulsion as base material, compounded with fillers, weather-resistant pigments and functional additives. This eco-friendly water-borne system contains no asbestos, lead, mercury or other heavy metals. It features excellent UV resistance, water resistance, wear resistance and anti-slip performance. It can be constructed on asphalt and qualified cement-concrete substrates. Suitable for courts of schools, clubs and commercial venues, and complies with ITF hard-court performance requirements.
| Item | Specification | Test Standard |
|---|---|---|
| Appearance | Homogeneous colored paste without agglomerates | Visual inspection |
| Color | Court green, court blue, bright red; custom colors available | — |
| Density | 1.33-1.37 g/cm³ | GB/T 6750 |
| Solid Content | 50±2 % | GB/T 1725 |
| VOC Content | ≤50 g/L | GB 24408-2009 |
| Dilution Method | Purified water, maximum dosage: 5-10% | — |
| Surface-dry Time | 1-2 h (25℃, 50%RH) | GB/T 1728 |
| Recoating Interval | 4-6 h, minimum 3 h | GB/T 1728 |
| Full Curing | 7 days (25℃) | — |
| Pencil Hardness | ≥H | GB/T 6739-2022 |
| Cross-cut Adhesion | ≤Grade 1 (Asphalt / Concrete) | GB/T 9286-2021 |
| Tensile Strength | ≥0.65 MPa | GB/T 1040 |
| Taber Abrasion (1000 r) | ≤0.05 g | GB/T 22374-2018 |
| Dry-state Anti-slip BPN | 80-105 | GB/T 24508 |
| Ball Rebound Rate | ≥90% | — |
| QUV Artificial Weathering (500 h) | Color difference ΔE ≤3, no chalking or cracking | GB/T 1865 |
Sealer Primer: Acrylic penetrating primer. Seals the substrate and improves bonding performance; dilute with clean water and apply by roller.
Reinforcing Levelling Layer: Acrylic mixed with quartz sand and cement. Repair substrate voids and level the surface.
Elastic Shock-absorbing Layer: Elastic acrylic binder mixed with rubber granules and rubber powder to provide elastic cushioning.
Textured Filler Layer: Acrylic mixed with refined quartz sand, to form court surface roughness and control ball speed.
Color Top Coat: 2 coats, weather-resistant colored finish layer.
Line Paint: Special water-based acrylic marking paint for court line marking.
Final finished thickness: - Hard court: 1.5-2 mm - Elastic system: 3-5 mm - Professional competition grade: 5-8 mm
Construction ambient temperature: 5℃～35℃, optimal range: 15-30℃ Ambient relative humidity: ≤85%; No standing water or condensation on substrate. Construction is prohibited in rainy weather.
Substrate Requirements
- Asphalt Substrate: Compact and flat, unidirectional drainage slope of 0.5-0.8%; fully cured. - Concrete Substrate: Grade C25 or above, curing period ≥28 days; waterproof treatment shall be carried out; cracks shall be properly repaired.
Theoretical Application Rate
- Primer: 0.15-0.20 kg/㎡ per coat - Reinforcing Levelling Layer: 0.6-0.8 kg/㎡ per coat (mixed with quartz sand) - Elastic Layer: 0.8-1.2 kg/㎡ per coat (mixed with rubber granules) - Textured Filler Layer: 0.7-0.9 kg/㎡ per coat (mixed with quartz sand) - Color Top Coat: 0.3-0.4 kg/㎡ per coat
Tools: Rubber squeegee, roller, trowel, electric mixer, grinding machine. Stir each batch of materials thoroughly before construction.
Storage temperature: 5-35℃. Freezing is strictly prohibited. Store in original sealed drums; keep away from direct sunlight and heat sources. Shelf-life: 12 months for unopened original packaging.
- Water-borne eco-friendly system, free of asbestos, lead, mercury and other harmful substances. - Excellent weather resistance and UV resistance; resistant to fading and chalking for long-term outdoor application. - Water-resistant and water-permeable; realize site drainage together with substrate slope design. - Moderate elasticity reduces joint impact during sports; excellent anti-slip & wear-resistant property with stable ball rebound performance. - Available for renovation of old acrylic courts, easy maintenance and repair work.
Actual performance depends on substrate condition, construction process and climatic environment. All data are test values obtained under standard laboratory conditions. Read this document and the corresponding SDS (Safety Data Sheet) completely before construction. Conduct test-patch application on-site to confirm color and construction compatibility before large-area construction. All technical parameters in this TDS are for reference only and do not constitute legal warranty.
奥益AOYI水性丙烯酸球场涂料
文档版本：V1.0
日期：2026-09-01
产品型号：水性丙烯酸球场系统）
生产单位：广州市联益化工有限公司
适用场地：网球场、篮球场、匹克球场、排球场等户外运动场地
AC-SP-500 为单组份水性弹性丙烯酸运动场地涂料，以丙烯酸弹性乳液为基料，搭配填料、耐候颜料、功能性助剂制成。环保水性体系，无石棉、无铅汞重金属；具备优异耐紫外线、防水、耐磨、防滑性能，可在沥青、合格水泥混凝土基础施工，满足学校、俱乐部、商业球场使用，可适配 ITF 硬地球场性能要求。
| 项目 | 技术指标 | 测试标准 |
|---|---|---|
| 外观 | 均匀膏状色浆，无结块 | 目视 |
| 颜色 | 球场绿、球场蓝、大红，可定制 | — |
| 密度 | 1.33-1.37 g/cm³ | GB/T 6750 |
| 固含量 | 50±2 % | GB/T 1725 |
| VOC 含量 | ≤50 g/L | GB 24408-2009 |
| 稀释方式 | 纯净水，最大添加量 5-10% | — |
| 表干时间 | 1-2 h（25℃，50%RH） | GB/T 1728 |
| 重涂间隔 | 4-6 h，最低不少于 3h | GB/T 1728 |
| 完全固化 | 7 天（25℃） | — |
| 铅笔硬度 | ≥H | GB/T 6739-2022 |
| 划格附着力 | ≤1 级（沥青 / 混凝土） | GB/T 9286-2021 |
| 拉伸强度 | ≥0.65 MPa | GB/T 1040 |
| Taber 耐磨（1000r） | ≤0.05g | GB/T 22374-2018 |
| 干态抗滑 BPN | 80-105 | GB/T 24508 |
| 球反弹率 | ≥90% | — |
| 耐人工老化 QUV 500h | 色差 ΔE≤3，无粉化开裂 | GB/T 1865 |
封闭底涂 Primer：丙烯酸渗透底涂，封闭基础，提高粘结；加水稀释滚涂
增强找平层：丙烯酸 + 石英砂+水泥，修补基面孔隙，找平
弹性减震层：弹性丙烯酸胶水混合橡胶颗粒和像胶粉，提供弹性缓冲
纹理填充层：丙烯酸 + 精制石英砂，构建球场粗糙度，调控球速
彩色面涂层 Color Coat：2 道，耐候着色面层
划线漆 Line Paint：球场标线专用水性丙烯酸划线漆
总成型厚度：硬地 1.5-2mm；弹性系统 3-5mm；专业赛事可达 5-8mm
施工环境温度：5℃～35℃，最佳 15-30℃
环境相对湿度：≤85%；基面不能有水、结露；下雨禁止施工
基础要求
沥青基础：密实平整，坡度 0.5-0.8% 单向排水；养护完成
混凝土基础：C25 以上，养护≥28 天，做防水处理，裂缝修补到位
理论涂布用量
底涂：0.15-0.20 kg/㎡/ 道
增强找平层：0.6-0.8 kg/㎡/ 道（混石英砂）
弹性层：0.8-1.2 kg/㎡/ 道（混橡胶颗粒）
纹理填充层：0.7-0.9 kg/㎡/ 道（混石英砂）
彩色面涂：0.3-0.4 kg/㎡/ 道
工具：橡胶刮耙、滚筒、镘刀、搅拌器、打磨机；每批次材料搅拌均匀再施工
储存温度：5-35℃，严禁冰冻
密封原装桶存放，远离日晒热源
保质期：原厂未开封 12 个月
水性环保体系，不含石棉、铅、汞有害物质
优异耐候抗紫外线，户外长期使用不易褪色粉化
防水透水，配合基础坡度实现场地排水
适度弹性，降低运动关节冲击；防滑耐磨，球反弹稳定
可翻新旧丙烯酸球场，维护修补简便
实际性能受基础状况、施工工艺、环境气候影响，本数据为实验室标准条件下测试值。
施工前完整阅读本文档以及对应 SDS 安全数据表。
客户现场务必做小样试涂，确认颜色、施工适配性再大面积施工。
本 TDS 技术参数仅供技术参考，不作为法律担保文件。
